LED Warning Light
Description
Using the latest patent technology, the LED warning light meets SAE requirements. It features an even and strong light. The T-3x4 lamp and chrome surface housing can be attached together, or the lamp can be installed in a recessed installation.
- T-DRL06
- T-DRL01
- T-DRL02
- W3Q4-BL
- W3Q4-R
Specification:
Operating Voltage: DC10-33V,DC12V,DC24V
Operating Temperature: -40~65℃
Light Source: Gen2 super fluc efficient LEDs, with low power consumption
Light Color: Red, Amber, Blue, White, Green, White, colored lens or clear lens with colored LEDs
Exterior flasher or Built-in flasher with 8 flash light patterns, including standard quad flash and double flash
Optional flash light pattern, by using the white wire to touch the black wire "_"
Synchronous or alternate flash patterns.
Reverse polarity protect
UV resistant of PC outer lens
Comply with ECE R65 requirements
IP67
Applications:
The warning light is widely used in cabinets, cabins, busses, caravans, shelters, refrigerator cars, and specialty vehicles.
